使用Ansible对京东云服务器初始化
概要：由于公司业务扩展，需要在线上新增30台服务器，系统为Ubuntu22.04 EFI版本，这么多要是人肉那着实有点蓝瘦，所以使用了Ansible进行部署，当然仅仅是对系统简单的初始化，配置相关环境(文章也算对工作做个记录)。
1. 准备相关目录结构
╭─ ~/Desktop/WolfWorkFile/DevOps/Ansible/ansible_ops ························································································· ✔ at 13:55:16 ─╮ ╰─ tree ├── ansible.cfg ├── hosts # 主机列表 ├── inventory ├── playbooks │ ├── JD_os_ubuntu2204_init.yaml # 指定运行role的路径 ├── roles │ ├── JD_os_ubuntu2204_init │ │ ├── default │ │ ├── files │ │ ├── handlers │ │ ├── meta │ │ ├── tasks # 对系统进行初始化 │ │ │ ├── hostname_set.yml # 自动对系统进行命名 │ │ │ ├── main.yml # 主入口，就是你要执行哪些tasks中的yml文件 │ │ │ ├── os_env.yml # 系统环境初始化(环境变量，部分系统参数) │ │ │ ├── service_config.yml # 安装自定义的一些服务(systemd)，对应服务文件在templates中 │ │ │ ├── service_enable_start.yml # 启动自定义服务 │ │ │ └── software_install.yml # 系统初始化安装一些软件，包括jdk node_export等 │ │ ├── templates # 这里模板文件 定义了2个系统服务(systemd) │ │ │ ├── node-exporter.service │ │ │ └── process-exporter.service │ │ └── vars │ │ └── os_name_var.yml # 在tasks中使用的变量 └── Shell ├── Centos79_init.sh └── Python399_install.sh2. 编辑host(请注意我已经使用了ssh-key所以不用输入账号密码)
# vi hosts [all:vars] ansible_ssh_user=root [jdcloud] # 主机列表 116.x.x.x 116.x.x.x ...3. 编辑vars(ansible用到的环境变量)
# vi roles/vars/os_name_var.yml cloud: JD zone: CN application: Service #application: DBService4.编辑tasks任务
4.1 系统命名
# vi roles/JD_os_ubuntu2204_init/tasks/hostname_set.yml - name: Get public IP #shell: curl -s ifconfig.me shell: curl ip.sb register: public_ip changed_when: false - name: Set IP variable set_fact: ip_last_two: "{{ public_ip.stdout.split(.)[-2:] | join() }}" - name: Set hostname ansible.builtin.command: cmd: "hostnamectl set-hostname --static {{ cloud }}-{{ zone }}-{{ application }}-{{ ip_last_two }}" become: yes4.2 系统环境初始化
# vi roles/JD_os_ubuntu2204_init/tasks/os_env.yml - name: Backup sysctl.conf ansible.builtin.copy: src: /etc/sysctl.conf dest: /etc/sysctl.conf_bak remote_src: yes - name: Update sysctl.conf ansible.builtin.lineinfile: path: /etc/sysctl.conf line: vm.max_map_count=262144 create: yes - name: Set nproc and memlock limits ansible.builtin.lineinfile: path: /etc/security/limits.conf line: "{{ item }}" loop: - "* soft nproc 102400" - "* soft memlock unlimited" - "* hard memlock unlimited" - name: Set sysctl parameters ansible.builtin.sysctl: name: "{{ item.name }}" value: "{{ item.value }}" state: present sysctl_set: yes reload: yes loop: - { name: net.core.somaxconn, value: 65535 } - { name: net.core.netdev_max_backlog, value: 65535 } - { name: net.ipv4.tcp_max_syn_backlog, value: 65535 } - { name: net.ipv4.ip_local_port_range, value: 1024 65535 } - { name: fs.file-max, value: 500000000 } - { name: fs.nr_open, value: 10000000 } - name: Set nofile soft limit ansible.builtin.pam_limits: domain: * limit_type: soft limit_item: nofile value: 65536 - name: Set nofile hard limit ansible.builtin.pam_limits: domain: * limit_type: hard limit_item: nofile value: 65536 - name: Set JAVA_HOME environment variable ansible.builtin.lineinfile: path: /etc/profile line: export JAVA_HOME=/usr/local/jdk17 create: yes - name: Set CLASSPATH environment variable ansible.builtin.lineinfile: path: /etc/profile line: export CLASSPATH=.:$JAVA_HOME/jre/lib/rt.jar:$JAVA_HOME/lib/dt.jar:$JAVA_HOME/lib/tools.jar create: yes - name: Set PATH environment variable ansible.builtin.lineinfile: path: /etc/profile line: export PATH=$PATH:$JAVA_HOME/bin create: yes4.3 cp自定义系统systemd服务
# vi roles/JD_os_ubuntu2204_init/tasks/service_config.yml # 服务的模板在templates中 - name: Copy node-exporter.service ansible.builtin.template: src: node-exporter.service dest: /usr/lib/systemd/system/node-exporter.service mode: 0644 - name: Copy process-exporter.service ansible.builtin.template: src: process-exporter.service dest: /usr/lib/systemd/system/process-exporter.service mode: 06444.4 启动自定义systemd服务
# vi roles/JD_os_ubuntu2204_init/tasks/service_enable_start.yml - name: Start and enable services at boot ansible.builtin.systemd: name: "{{ item }}" state: started enabled: yes loop: - node-exporter - process-exporter - name: Reboot the system ansible.builtin.reboot: - name: Wait for system to become reachable again ansible.builtin.wait_for_connection: delay: 60 timeout: 3004.5 服务器软件安装
# vi roles/JD_os_ubuntu2204_init/tasks/software_install.yml - name: Update APT package cache ansible.builtin.apt: update_cache: yes - name: Install required packages ansible.builtin.apt: name: - wget - unzip - tree - htop - btop - atop - nload - net-tools - bash-completion - tcpdump - mtr - iperf3 - lrzsz - expect - nethogs - psmisc - lsof - iotop - iftop state: present - name: Create directory ansible.builtin.file: path: /root/software state: directory - name: Download software ansible.builtin.get_url: url: http://192.168.1.12:9999/work/os_init/os_ubuntu2204_init_software.tar.gz dest: /root/software/ - name: Extract software ansible.builtin.unarchive: src: /root/software/os_ubuntu2204_init_software.tar.gz dest: /usr/local/ remote_src: yes4.6 定义tasks执行顺序main.yml
# vi roles/JD_os_ubuntu2204_init/tasks/main.yml - include_vars: vars/os_name_var.yml # - include_vars: vars/os_env.yml # - include_vars: vars/consul_env.yml - include_tasks: tasks/hostname_set.yml - include_tasks: tasks/software_install.yml - include_tasks: tasks/os_env.yml - include_tasks: tasks/service_config.yml - include_tasks: tasks/service_enable_start.yml5.定义systemd启动模板
# vi roles/JD_os_ubuntu2204_init/templates/node-exporter.service # prometheus 主机监控(linux)node-export启动 [Unit] Description=Node Exporter Documentation=https://github.com/prometheus/node_exporter After=network.target [Service] User=root ExecStart=/usr/local/node-exporter-1.8.2/node_exporter Restart=on-failure [Install] WantedBy=multi-user.target ----------------------------- # vi roles/JD_os_ubuntu2204_init/templates/process-exporter.service # prometheus 系统进程(linux)process-export启动 [Unit] Description=Prometheus exporter for processors metrics, written in Go with pluggable metric collectors. Documentation=https://github.com/ncabatoff/process-exporter After=network.target [Service] Type=simple User=root WorkingDirectory=/usr/local/process-exporter-0.8.4 ExecStart=/usr/local/process-exporter-0.8.4/process-exporter -config.path=/usr/local/process-exporter-0.8.4/process_name.yaml Restart=on-failure [Install] WantedBy=multi-user.target6.软件包结构
╭─ ~/Dev/os_ubuntu2204_init_software ··········· ✔ at 14:24:36 ─╮ ╰─ tree -L 1 ─╯ . ├── jdk17 ├── node-exporter-1.8.2 └── process-exporter-0.8.47.编辑并执行Playbook
# 编辑Playbook vi playbooks/JD_os_ubuntu2204_init.yaml - hosts: jdcloud # 这里是读取hosts文件中的jdcloud中的主机列表 roles: - ../roles/JD_os_ubuntu2204_init # 执行角色为roles中JD_os_ubuntu2204_init角色# 注意执行路径要在根文件夹下面 ╭─ ~/Desktop/WolfWorkFile/DevOps/Ansible/ansible_ops ························································································· ✔ at 13:55:25 ─╮ ╰─ ls ─╯ ansible.cfg hosts inventory playbooks roles Shell # 执行playbook ansible-playbook playbooks/JD_os_ubuntu2204_init.yaml -i hosts
image-20250728172619057
